Diesel Forklift 5.0t-7.0t

Appearance
The latest appearance design method was used to create the R series fluent and aesthetic outline, which matches the latest appearance trend.

Efficiency
Thanks to the long wheelbase design, the longitudinal stability of whole truck is much better, the hoisting capacity at same lift height are enhanced by an average of 100KG compared with former truck. At the same time, it prolongs work time of rear wheel as the reduced rear axle’s load.

The travel speed of truck has been raised, for example, the 2-2.5T type comes to 20km/h.

Turning radius and width of right angle stacking aisle are decreased through reducing the dimensions of whole truck, that raise the efficiency of storehouse.

Service
Dual air spring supporting hood and one-touch removal of the floorboard get you right to service operations, and reduces down-time.

The reasonable arrangement of fuse and installation of instrument, enable the replacing for fuse and maintenance for instrument easier.

Clean
The environment friendly engines all meet EU stage-2 emission control regulation. The noise emission also comes to EU standard.
The metal hood and molding sound insulation matches environmental protection demands.

Safe
A throttling device is set in pipe system，the mast won’t result in failing control of mast even some pipes broke.
By using a built-in hood lock device, the safe level of the truck has been raised.

Model	Power type	Rated capacity (kg)	Load center (mm)	Lift height (mm)	Engine			Trans-mission
					Model	Manu-facture	Rated output (kw/rpm)
					Model	Manu-facture	Rated output (kw/rpm)
CPCD50N-RW14	Diesel	5000	600	3000	6BG1QP	ISUZU	84.6/2200	CHINA
CPCD60N-RW14	Diesel	6000	600	3000	6BG1QP	ISUZU	84.6/2200	CHINA
CPCD70N-RW14	Diesel	7000	600	3000	6BG1QP	ISUZU	84.6/2200	CHINA
CPCD50N-RW14B	Diesel	5000	600	3000	6BG1QP	ISUZU	84.6/2200	CHINA
CPCD60N-RW14B	Diesel	6000	600	3000	6BG1QP	ISUZU	84.6/2200	OKAMURA
CPCD70N-RW14B	Diesel	7000	600	3000	6BG1QP	ISUZU	84.6/2200	OKAMURA
CPCD50N-RW19A	Diesel	5000	600	3000	TD42	NISSAN	62.5/2300	NISSAN
CPCD60N-RW19A	Diesel	6000	600	3000	TD42	NISSAN	62.5/2300	NISSAN
CPCD50N-RW28	Diesel	5000	600	3000	QSB4.5	CUMMINS	82/2200	CHINA
CPCD60N-RW28	Diesel	6000	600	3000	QSB4.5	CUMMINS	82/2200	CHINA
CPCD70N-RW28	Diesel	7000	600	3000	QSB4.5	CUMMINS	82/2200	CHINA
CPCD50N-RG16	Diesel	5000	600	3000	CY6102BG	CHINA	81/2500	CHINA
CPCD60N-RG16	Diesel	6000	600	3000	CY6102BG	CHINA	81/2500	CHINA
CPCD70N-RG16	Diesel	7000	600	3000	CY6102BG	CHINA	81/2500	CHINA
CPCD50N-RG24	Diesel	5000	600	3000	LR4108G10Y	CHINA	65/2400	CHINA
CPCD60N-RG24	Diesel	6000	600	3000	LR4108G10Y	CHINA	65/2400	CHINA
CPCD70N-RG24	Diesel	7000	600	3000	LR4108G10Y	CHINA	65/2400	CHINA

Type	Model	Max. fork Height	Overall height		Free lift	Tilt range
			Extended		With backrest	FWD	RWD
			Lowered	With Backrest	With backrest	FWD	RWD
		mm	mm	mm	mm	Deg	Deg
Wide view mast	50M. 7M	2500	2250	3920	160	6	12
		2700	2350	4120	160	6	12
		3000	2500	4420	160	6	12
		3300	2650	4720	160	6	12
		3600	2800	5020	160	6	12
		4000	3000	5420	160	6	12
		4300	3200	5720	160	6	6
		4500	3300	5920	160	6	6
		4800	3450	6220	160	6	6
		5000	3550	6420	160	6	6
		5500	3850	6920	160	3	6
		6000	4100	7420	160	3	6
Wide view full free 2-stage mast	50U. 7U	2500	2185	3640	1048	6	12



Wide view full free 3-stage mast	50NX. 7N	4000
		4500	2720	5920	1323	6	6
		4800	2820	6220	1423	6	6
		5000	2870	6420	1473	6	6
		5500	3070	6920	1673	3	6
		6000	3220	7420	1823	3	6
		7000	3670	8420	2273	3	6

The Standard mast of forklift is 2-stasge 3000mm, different mast specifications are provided above.
